单通道全桥驱动

兆易创新面向有刷电机提供多种规格的单通道全桥驱动类产品。支持更宽范围的电机工作电压，提供更强的驱动能力，支持多种故障保护及故障指示功能，支持多种电流检测方式。

下载到电子表格中

Part NO.	Supply Voltage (V) Min	Supply Voltage (V) Max	Gate Driver	Power MOSFET	Drive Current (A)	Control Interface	Current Sensor	Protection Features	Itrip Funcation	PWM Frequency (kHz) Max	Temperature Junction Range (°C)	Package	MPQ（PCS）	MOQ（PCS）
GD30DR8413EUTR	4.5	30	-	Internal	3	3xPWM	extend	OCP/SCP/TSD/UVLO	NA	50	-40℃~125℃	QFN24	3000	3000
GD30DR3000WGTR-K	6.5	40	-	Internal	3.2	PWM	extend	OCP/SCP/TSD/UVLO	Support	100	-40℃~125℃	ESOP8	4000	4000
GD30DR3001WGTR-K	4.5	40	-	Internal	6A Peak 4A Continuous	PWM	extend	OCP/SCP/TSD/UVLO	Support	200	-40℃~125℃	EP-SOP8	4000	4000
GD30DR3002WGTR-K	4.5	40	-	Internal	6A Peak 4A Continuous	PWM	extend	OCP/SCP/TSD/UVLO/nFault Instruction	Support	200	-40℃~125℃	EP-SOP8	4000	4000
GD30DR3003WGTR-K	4.5	40	-	Internal	6A Peak 4A Continuous	PWM	Internal	OCP/SCP/TSD/UVLO	Support	200	-40℃~125℃	EP-SOP8	4000	4000
GD30DR3004WGTR-K	6.5	60	-	Internal	3.2	PWM	extend	OCP/SCP/TSD/UVLO	Support	100	-40℃~125℃	ESOP8	4000	4000
GD30DR3800WETR-K	0	11	-	Internal	1.8	PWM	-	OCP/SCP/TSD/UVLO	NA	250	-40℃~85℃	DFN8	3000	3000
GD30DR3800WGTR-K	0	11	-	Internal	1.8	PWM	-	OCP/SCP/TSD/UVLO	NA	250	-40℃~85℃	SOP8	3000	3000
GD30DR3801WETR-K	0	10	-	Internal	1	PWM	-	OCP/SCP/TSD/UVLO	NA	250	-40℃~85℃	DFN8	3000	3000
