DC-DC转换器

兆易创新提供的DC-DC转换器产品包含BUCK（降压）转换器和BOOST（升压）转换器，具有输入耐压高、输出电流大、输入功耗低以及输出纹波小等优势，同时提供丰富封装选择和完整的产品线。该系列DC/DC转换器产品可广泛用于通讯、工业、安防、智能穿戴、物联网(IoT)、消防等领域。

下载到电子表格中

Part NO.	Status	Function	Supply Voltage (V)Min	Supply Voltage (V)Max	Output Current (A)Max	Ron (mΩ) HSFET	Ron (mΩ) LSFET	Reference Voltage (V)	Quiescent Current (μA)	Switching Frequency (MHz)	Note	Temperature Operating Range(°C)	Package
GD30DC1103NSTR-I	MP	BUCK	2.5	6	1	200	150	0.6	25	1.5	SS/Comp./Current Mode	-40 to +85	SOT235
GD30DC1107NSTR-I	MP	BUCK	2.5	6	1	200	150	0.6	-	1.5	SS/Comp./Current Mode/FCCM	-40 to +85	SOT235
GD30DC1103SOTR-I	MP	BUCK	2.5	6	1	200	150	0.6	25	1.5	SS/Comp./Current Mode	-40 to +85	SOT563
GD30DC1106NSTR-I	MP	BUCK	2.5	6	1.2	200	150	0.6	25	1.5	SS/Comp./Current Mode	-40 to +85	SOT235
GD30DC1109NSTR-I	MP	BUCK	2.5	6	1.2	200	150	0.6	-	1.5	SS/Comp./Current Mode/FCCM	-40 to +85	SOT235
GD30DC1104NSTR-I	MP	BUCK	2.7	5.75	2	65	60	0.6	35	1.5	SS/Comp./Current Mode	-40 to +85	SOT235
GD30DC1108NSTR-I	MP	BUCK	2.7	5.75	2	65	60	0.6	-	1.5	SS/Comp./Current Mode/FCCM	-40 to +85	SOT235
GD30DC1301SOTR-I	MP	BUCK	4.5	18	2	110	60	0.8	250	0.8	ACOT	-40 to +85	SOT563
GD30DC1301SSTR-I	MP	BUCK	4.5	18	2	110	60	0.8	250	0.8	ACOT	-40 to +85	SOT236
GD30DC1301SOTR-S	MP	BUCK	4.5	18	2	110	60	0.8	250	0.8	ACOT	-40 to +85	SOT563
GD30DC1301SSTR-S	MP	BUCK	4.5	18	2	110	60	0.8	250	0.8	ACOT	-40 to +85	SOT236
GD30DC1307SSTR-I06	MP	BUCK	4.2	18	2	113	80	0.6	250	0.6	ACOT	-40 to +85	SOT236
GD30DC1307SSTR-I12	MP	BUCK	4.2	18	2	113	80	0.6	250	1.2	ACOT	-40 to +85	SOT236
GD30DC1300SOTR-I	MP	BUCK	4.5	18	3	80	45	0.8	250	0.8	ACOT	-40 to +85	SOT563
GD30DC1300SSTR-I	MP	BUCK	4.5	18	3	80	45	0.8	250	0.8	ACOT	-40 to +85	SOT236
GD30DC1300SOTR-S	MP	BUCK	4.5	18	3	80	45	0.8	250	0.8	ACOT	-40 to +85	SOT563
GD30DC1300SSTR-S	MP	BUCK	4.5	18	3	80	45	0.8	250	0.8	ACOT	-40 to +85	SOT236
GD30DC1309ZUTR-I	MP	BUCK	4.5	18	6	21	16	0.6	750	0.2-1.6	SS/Comp./Current Mode/FCCM	-40 to +150	QFN14
GD30DC1350SSTR-I	MP	BUCK	4.5	25	3	50	40	0.6	175	0.5	ACOT	-40 to +85	SOT236
GD30DC2300SSTR-N	MP	BOOST	2.5	18	-	-	150	0.6	110	1	Current Mode	-20 to +85	SOT236
GD30DC2301SSTR-N	MP	BOOST	2.5	18	-	-	150	0.2	110	1	Current Mode	-20 to +85	SOT236
GD30DC2101SSTR-I	MP	BOOST	0.9	5.5	-	600	300	0.5	1	1	Current Mode	-40 to +125	SOT236
GD30DC2100SSTR-I	MP	BOOST	0.9	5.5	-	600	300	0.5	1	1	Current Mode	-40 to +125	SOT236
GD30DC1305SOTR-I08	MP	BUCK	4.2	18	2	95	70	0.6	260	0.8	ACOT	-40 to +85	SOT563
GD30DC1310SSTR-I06	MP	BUCK	4.2	18	2	113	80	0.8	250	0.6	ACOT	-40 to +85	SOT236
GD30DC1310SOTR-I08	MP	BUCK	4.2	18	2	95	70	0.8	260	0.8	ACOT	-40 to +85	SOT563
GD30DC1314SSTR-I06	MP	BUCK	4.2	18	2	113	80	0.765	250	0.6	ACOT	-40 to +85	SOT236
GD30DC1318SSTR-I06	MP	BUCK	4.5	18	3	95	60	0.6	250	0.6	ACOT	-40 to +85	SOT236
